Brochure - AH渣浆泵 warman
产品概述
The versatile, fully lined Warman AH offers a wide rangeof seal and liner configurations allowing the pump to betailored to the customer's specific application.
产品参数
| Performance and advantages | ●Bearing assembly — A large diameter shaft withshort overhang minimizes deflection and contrib-utes to long bearing life. Only four through boltsare required to hold the cartridge type housing inthe frame ●Liners — Easily replaceable liners are bolted, notglued, to the casing for positive attachment andease of maintenance. Hard metal liners are com-pletely interchangeable with pressure molded elas-tomers. Elastomer seal ings back all liner joints ●Casing — Casing halves of cast or ductile iron withexternal reinforcing ribs provide high operatingpressure capabilities and an extra measure of safety ●Impeller — Front and rear shrouds have pump outvanes that reduce recirculation and seal contamina-tion. Hard metal and molded elastomer impellersare completely interchangeable. Cast in impellerthreads require no inserts or nuts. High efficienyand high head designs are also available ●Throatbush — Wear is reduced and maintenancesimplified by the use of tapered mating faces toallow positive accurate alignment during assemblyand simple removal ●One-piece frame — A very robust one-piece framecradles the cartridge type bearing and shaft assem-bly. An external impeller adjustmen mechanismis provided below the bearing housing for easyadjustment of impeller clearance |
服务无忧
公司建立了完善的营销服务网络，在不断满足国内市场需求的同时积极出口海外市场，产品广泛应用增压，工业应用，水处理，生活供水，空调水循环，供暖，消防系统，地下水供应，污水废水处理，化工行业和海水淡化等诸多领域),销售主导产品有：CDL、CDLF系列不锈钢轻型多级离心泵，CHL,CHLF,CHLFT系列不锈钢轻型多级离心泵；NFWG无负压变频供水设备、DRL恒压变频供水设备
